Substation Commissioning and Protection Training Services

TDx Power owns a range of specialised testing and commissioning equipment which we use for protection training and field testing and commissioning services.
Our philosophy is that a solid understanding of power system fundamentals is best understood by engineers with actual hands on testing and commissioning experience.

TDx Power’s complement of commissioning equipment includes the following:

• OMICRON CPC100 primary injection set;

• OMICRON CMC256 injection test set;

• OMICRON CT Analyzer;

• SEL (Schweitzer Engineering Laboratories) demonstration substation protection and automation system consisting of SEL 351S, 221F and 2030F relays and communications processors;

• a wide collection of electromechanical relays which are used for training purposes;

• Megger DET2/2 high accuracy earth electrode and soil resistivity tester and DEHN earth testing equipment;

• Impedograph quality of supply meter (capable of power quality and transient measurements and recordings of three phase voltages and currents);

• Landis + Gyr ZMD and Elster Kent A1700 class 0.5 four quadrant tariff meters.

Our protection training and commissioning services include the following:

• protection and automation training;

• substation commissioning tests;

• protection tests and investigations;

• soil resistivity and earth electrode resistance tests and investigations;

• quality of supply / power quality tests and investigations;

• load recordings; and

• tariff and electricity billing measurements and investigations.
